Material : Aluminum alloy
Operating temperature range : 1.5 to 65 °C
Operating pressure range : 0 – 20 bar
Connection : 1/2’’
No electric power required
Easy to install and maintain
No air loss
Non corrosive SS float
Super light Aluminum body
The is used when larger amounts of condensate (up to 300 l/h) must be automatically discharged from filters, pressure vessels and cyclone separators. When the condensate exceeds the discharge level, the float rises, opens the discharge port and discharges condensate from the system.
Mechanical float type drains are provided with a Y-type strainer & a nipple which will improves the performance of the drain valve.
